01.

Rotor line

R01: Apply adhesive to the shell, insert the magnet, assemble the hub

R02: Glue curing

R03: Dial gauge, finishing, vibration detection equipment

R04: Dynamic balancing tester Visual inspection by hand

R01

R02

R03

R04

02.

Stator line

S01: Stator winding Machine

S02: Cable management and paint removal
S03: Solder an extension cable and fit heat shrink tubing

S04: Finished Stator Testing

S05: Skeleton assembly
S06: Glue curing

S01

S02

S03

S04

S05

S06

03.

Motor Assembly line

M01: Bearing assembly

M02: Stator and rotor assembly
M03: Gasket Loading and Tightening

M04: No-load test

M05: Laser marking
M06: Packaging

M01

M02

M03

M04

M05

M06
